Cobalt Spa

From $10,499
Seating
Dimensions
2.15 x 2.15 x 0.92m
Volume
1,200 ltr
Weight (full)
1,517 kg
Jets
Up to 66
Hydrotherapy
Spec
Tech Info

Why choose a Vortex Cobalt?

Compact perfomance

At 2.15m x 2.15m, the Cobalt sits in between the 2m Cerium and the 2.3m Nitro in Vortex's hydrotherapy spa range. Whilst it includes all the performance of the Nitro, it's size makes it less imposing.

Up to 600 litre per minute Volcano jet

Up to 66 hydrotherapy jets and the neck and shoulder therapy collar have all the bases covered when it comes to relaxation in the Cobalt. It is also the smallest of the Vortex range to include a volcano jet in a central position in the pool to allow for treatment of hamstrings, glutes and the front of the body.

Comfortable for 5

It's amazing how much extra room in the spa the additional 150mm of size gives. Unlike 2 metre, 5 seater spas like the Mercury, the Cobalt will comfortable seat 5 adults, although you will be a little closer together than you would find yourself in the 2.3 metres spas in the range.

Neck and shoulder therapy

Like many of the Vortex range, the Cobalt HP includes a neck and shoulder therapy seat although the collar is an optional feature and very tall people should check they fit under it before ordering.

Twin longers

Like all two lounger Vortex spas, the Cobalt's loungers are different depths to account for the varying heights of it's users.

Cobalt Avanté upgrade

The Vortex Avanté is a collection of our best
selling upgrades that makes your spa
longer
lasting, more economical and more
fun.
Standard Cobalt RRP $10,499
+ Hydroflow stainless steel jets $699
+ Hydroglow jet and topside control lighting $499
+ Backlit drink holders $199
+ Perimeter and cabinet lighting $499
+ Purezone UV water purifier $999
+ Backlit laminar jets $399
+ Dual layer insulation $499
+ Timber free Permaframe construction $699
Total value $14,991
Cobalt Avanté RRP $13,999

Add Hydroplus to your Cobalt

Like the rest of Vortex's Hydroplus or HP range, the Cobalt Hydroplus adds an additional jet pump to ensure optimum pressure through it's 66 stainless steel jets. In addition, it means that you can divert the pressure of one of these pumps to the Cobalt's volcano jet giving 600 litre per minute flow. The volcano jet is great for massaging hamstrings, glutes and even the front of the body, areas that are normally difficult to reach.

The extra pump also ups the power requirement at peak and so be sure you have a spare 32 amps available. Do bare in mind though that it's only going to draw this much power when all pumps are running so you shouldn't expect higher operational running costs.


Cobalt- from $10,499

Cobalt Avanté - from $13,999

1 Pump

Cobalt Hydroplus - from $11,499

Cobalt Hydroplus Avanté - from $14,999

2 Pumps

Blue jets are upgraded
Orange jets are additional

Spa World Rating

Overall

Energy Efficiency

Build Quality

In-Spa Experience

Water Cleaning Technology

Hydrotherapy

How we rate our spas

Choosing the right spa can be confusing. Especially when faced with many options to choose from. To simplify this process, we have used our years of spa experience to create a simple rating system that compares our huge range of spas across a number of important attributes.

Download spec sheet

Seating design

The Cobalt Hydroplus seats five adults in comfort.
Cobalt Hydroplus

Unable to load control '/_spa/Controls/SimilarSpas.ascx'!

Twin Lounger

A spa's lounger is undoubtably everyones favourite seat, but who wants to argue over who gets it? To maintain domestic bliss, the Cobalt Hydroplus has two loungers.

 Cobalt Hydroplus twin lounger

Two child seats

For those with younger children, it is often difficult to enjoy a spa without the children having to stand or sit on an adults lap. Child seats are designed to seat children with there heads comfortably out of the water. The can also provide secondary seating for adults if you are entertaining in your spa.

 Cobalt Hydroplus kids seat

Neck and shoulder therapy seat

As the name implies, the Neck and shoulder therapy seat has downward facing 50mm jets specifically designed to massage the back of the neck and the top of the shoulders. The neck and shoulder therapy seats also feature 6, 75mm jets for a great back massage.

 Cobalt Hydroplus neck shoulder therapy seat

Cobalt Hydroplus Features

In-Spa
Experience
Dual lounger seats

The Cobalt Hydroplus is a true hydrotherapy spa. It features two loungers equipped with expertly placed hydrotherapy and air jets that soothe and massage your whole body. As the loungers are always in high demand, the Cobalt Hydroplus has two, so they can be enjoyed together.

Neck therapy collar

The Cobalt Hydroplus's neck therapy collar is specifically designed to target the common tight spots around the neck and shoulders. 4 powerful 50mm hydrotherapy jets are embedded in the collar to target from above your neck and shoulders.

High pressure volcano jet

The Cobalt Hydroplus's high pressure volcano jet is situated in the center of the spa to create a world class hydrotherapy experience. The jet is positioned in the foot-well for the ultimate foot massage.

Individual seat pressure controls

Just as some people like firm mattresses and others like softer ones, the Cobalt Hydroplus allows you to adjust your jet pressure.  The Cobalt Hydroplus has individual jet pressure control for each seat to ensure everyone is satisfied.

Twin Laminar jets (optional)

Laminar jets create perfect streams of back lit water giving a gentle visual display. The jets operate independently of the hydrotherapy jets, so they can be turn your spa in to an impressive light display in your back yard.

Tranquil water feature

The Tranquil water feature gives your spa a relaxing feel with a gentle back lit water cascade. This water feature runs of the filtration pump, so it can be left running while your spa is not in use- turning it in to a garden water feature.

Illuminated glass holders (optional)

It is important to stay hydrated whilst using your spa, but at night, it can be hard to find where you've left your favorite beverage. The Vortex Cobalt Hydroplus has 3 illuminated glass rests so locating your drink is never a problem. They also tend to illuminate both the vessel and the liquid within it giving a nice lighting effect above the spa's water line.

Illuminated Topside Controls (optional)

Another thoughtful touch on the Cobalt Hydroplus spa is that the topside controls, which alter water and air flow, are illuminated. This makes them easy to locate at night and adds to the LED lights that illuminate various parts of the Cobalt Hydroplus.

Spa Health Indicator Light

The Vortex Spa health indicator light has been designed to communicate the spa’s condition to spa user without having to lift the cover. The indicator lights up blue to show it is at the correct temperature, or red to indicate a water temperature fluctuation over 5°C or a fault.

Spanet WiFi control (optional)

Control your spa remotely from anywhere in the world! With the optional Spanet wifi/bluetooth control unit, all you have to do is download the phone app (Android or Apple) and you can control all the spa functions simply and remotely. Also included is the SV HiFi which allows you to stream music from any bluetooth equipped smart device (phone, tablet etc). Sit back relax to your favorite music.

Color Options

Shell Colors
Pearl Shadow

Pearl Shadow
Oceanwave

Oceanwave


Gypsum
Stirling Silver

Stirling Silver

Cabinet Colors


Coastal Grey
Cabinet - Chocolate

Chocolate
Cabinet - Natural

Natural

Size, Volume and Weight

Spa measurement
Cobalt Hydroplus size
spa weight
Empty: 330kg

Full: 1,695kg
spa volume
Volume: 1,365 litres

Unable to load control '/_spa/Controls/SimilarSpas.ascx'!

Hydrotherapy

Hydrotherapy Rating

Jet Count

Cobalt standard
Cobalt Jet Layout
  • 1 x 130mm High Pressure Volcano Jet
  • 2 x 127mm Directional Jets
  • 4 x 127mm Single Spinning Jets
  • 2 x 127mm Twin Spinning Jets
  • 10 x 75mm Directional Jets
  • 10 x 50mm Directional Jets
  • 4 x 50mm Twin Spinner Jets
  • 24 x 40mm Air Jets
Cobalt Hydroplus
Cobalt Hydroplus Jet Layout
  • 1 x 130mm Hi Volcano Directional Jet
  • 8 x 127mm Directional Jets
  • 4 x 127mm Single Spinning Jets
  • 2 x 127mm Twin Spinning Jets
  • 10 x 75mm Directional Jets
  • 2 x 75mm Single Spinning Jets
  • 16 x 50mm Directional Jets
  • 12 x 50mm Twin Spinner Jets
  • 12 x 40mm Air Jets
Jet Types
130mm Hi Volcano Directional Jet
130mm Hi Volcano Directional Jet
1 x 130mm Hi Volcano Directional Jet These jets are either fitted into the footwell for the ultimate foot massage or positioned facing upwards in the middle of the spa to treat hamstrings, gluts, lower back and even the front of the abdomen.
127mm Directional Jet
127mm Directional Jet
8 x 127mm Directional Jets The 127mm directional jets provide and intense, pressure point massage. These are particularly effective at treating knotted muscles in the back.
127mm Single Spinning Jet
127mm Single Spinning Jet
4 x 127mm Single Spinning Jets This large single spinner gives a rotating massage effect similar to a masseuse using their thumb in a kneading fashion. They provide a very effective back massage.
127mm Twin Spinning Jet
127mm Twin Spinning Jet
2 x 127mm Twin Spinning Jets Like the 127mm single spinner, the twin spinning variation gives a kneading effect but by spinning at twice the speed of the single spinner, it gives more of a pulsating action.
75mm Directional Jet
75mm Directional Jet
10 x 75mm Directional Jets This style of directional jets gives a targeted but less intense pressure point massage. It's very effective for a more prolonged treatment of tired muscles.
75mm Single Spinning Jet
75mm Single Spinning Jet
2 x 75mm Single Spinning Jets The 75mm single spinning jets offer a similar effect as the larger 127mm variety but given their smaller size, the kneading effect is lighter and more focused.
50mm Directional Jet
50mm Directional Jet
16 x 50mm Directional Jets These jets are usually used in banks of 8 or more jets and are often coupled with 50mm twin spinners to give a shiatsu style pressure point massage therapy.
50mm Twin Spinning Jet
50mm Twin Spinning Jet
12 x 50mm Twin Spinning Jets The 50mm twin spinner offers a pulsating massage effect ideally suited for neck and shoulder therapy or as part of a shiatsu style massages treatment when teamed with 50mm directional jets.
40mm Air Jet
40mm Air Jet
12 x 40mm Air Jets As the name implies, the 40mm air jets emit an air stream as opposed to a water stream. These are almost always used under the legs and buttocks to provide a relaxing soft tissue massage treatment.

Unable to load control '/_spa/Controls/SimilarSpas.ascx'!

Energy Efficiency

Insulation
Consumption at rest
Consumption in use
Cover
Technologies

Programmable Circulation Pump

Up until recently, there were two types of filtration pump systems available. The first was a two speed pump which filtered on low speed and switched to high speed when the jets were turned on. Two speed pumps are still available, but the pumps are usually more noisy and less reliable.

The second system was a very small circulation pump which ran 24 hours a day regardless of whether you needed it to or not. The Vortex Cobalt instead uses a programmable circulation pump. It is quieter and more reliable than a two speed pump, but can be programmed to run for between 2 and 24 hours per day depending on how much the spa is being used.


Variable Output Heater

The heater of your spa draws more power than any other component. As a result, when the big jet pump or pumps turn on, the heater usually has to turn off, as unless your spa is hard wired, a conventional outdoor power point cannot provide enough power to run the heater and big jet pump at the same time.

The Vortex Cobalt however, has a variable output heater. This means when the spa's jet pump is turned on, the heater turns DOWN rather than OFF. This has the benefit of maintaining the spa's temperature while you are using it, rather than cooling it down.

High densityHigh Density Lid

As heat rises, most of the heat loss in a spa occurs through the spa's cover. As such, it is important that the spa's cover is manufactured from a high density foam that has better heat retention properties. The Vortex Cobalt uses a high density foam insert which is also heat shrink sealed to prevent water ingress, prolonging the cover's life.


Insulated Base

The insulated base works in tandem with the perimeter insulation to ensure the cold is kept out and heating costs are reduced.


Perimeter Insulation

There are several ways to insulate a spa. Vortex spas have chosen to use perimeter insulation. Whilst more expensive to produce than foaming the shell of the spa, it does have the benefit of insulating the water that is in the plumbing of the spa, as well as the water in the spa itself.


Dual Layer Insulation*

Acting like double glazed windows, the dual layer insulation system traps air between the foam insulation on the shell and the reflective foil and foam insulation of the cabinet, to create a pocket of warm air.

This system ensures that not only the water in the spa is insulated, but also the water in the pipework. This option adds a higher level of heat retention than Vortex’s standard perimeter insulation.

*optional on all Vortex spas


Arctic Insulation*

Vortex Spa’s optional Arctic pack insulation is the ultimate level of insulation available. It increasing the thickness of the perimeter insulation to 50mm gives unsurpassed heat retention and the lowest possible running costs.

This system is extensively used on Vortex Spas sold in very cold regions such as Scandinavia and Canada.

*optional on all Vortex spas

Water Cleaning

Ease of Use
Water Cleaning Technologies
Overall
maintenance cost
Technologies
UV Sterilizer (optional)

Using the power of ultra-violet light, the Water Sterilizer kills 99.9% of virus and bacteria. Giving you the safest possible spa pool water.

Ozone Water Clarifier

The Water Clarifier uses ozone technology to oxidize and remove micro organics and metals that are smaller than 5 microns resulting in the clearest water available.

Purezone Filtration

Ozone UV filter combo that removes both bugs and organics meaning you use even less chemicals.

Build Quality

Shell construction
Structure
Plumbing
Equipment
Warranty
Technologies
Thermobond shell construction

Vortex Spas use a 4 layer thermobond shell construction in the manufacturing of all of their spa shells.

The first layer is acrylic which gives the spa its colour. This is backed by a water proof, vinyl ester resin, marine grade polyester resin, which adds torsional strength, and, finally, a polyceramic layer which adds rigidity.

The shells are oven cured to ensure the correct bonding of the various layers. This is a crucial step that is missed by most manufacturers due to its additional cost.

Flexible PVC Plumbing

In order to eliminate the chance of kinks in the plumbing and to prolong life, Vortex Spas use a flexible PVC plumbing material called Duraflex. This is a flexible tubing that incorporates a spiral of rigid PVC. Unlike the tubing used by many manufacturers, Vortex Spas Duraflex plumbing is specifically designed for hot, chemically treated water and carries a 5 year no leak guarantee.

Timber-free frame (optional)

Vortex’s Permaframe construction is a timber-free framing system that is impervious to rot, mildew or vermin damage. Produced used high impact, injection molded plastic, it is designed to last indefinitely.

Vermin Proof Base

Vermin, snakes and rodents love the underside of spas as it is warm and dry. To repel unwanted visitors, the Cobalt Hydroplus features a sealed, Vermin proof base and cabinet design.

Lifetime warranty
Lifetime Warranty

Vortex's permaframe is guaranteed for life against a loss of structural integrity leading to the spa being inoperable.

10 Year Non Pro rata Structural Warranty

All Vortex Spas are offered with a 10 year 'non pro-rata' shell structure warranty. This means that if the spa's shell cracks resulting in water loss, for a period of 10 years, the spas shell shall be replaced.

5 Year Non Pro rata Acrylic surface warranty

All Vortex Spas are offered with a 5 year 'non pro-rata' acrylic surface warranty. This means that if the acrylic surface blisters resulting in water loss for a period of 5 years, the spa's shell shall be replaced

5 Year Plumbing, Heater  & Jet Warranty

The plumbing system of all Vortex spas is warranted against leaking for 5 years.

The heater and jets of all Vortex Spas are warranted against defects for a period of 5 years.

2 Year Pump & Equipment Warranty

The circulation pump, jet pump(s) and electronic control system of all Vortex spas are warranted against defects for 2 years.

*Please consult your local store for complete warranty details
